高压直流电缆直流载流量计算和验证

李栋; 王传博; 陈龙啸; 朱智恩; 杨黎明; 高凯; 曾浩

doi:10.16105/j.cnki.dxdl.2021.05.007

高压直流电缆直流载流量计算和验证

南瑞集团有限公司(国网电力科学研究院有限公司), 南京 211106

基金项目:

国家电网有限公司科技专项(5500-202058404A)；中国三峡新能源公司科技项目(524606200044)

详细信息

作者简介:
李栋(1988—),男,高级工程师,硕士。

中图分类号: TM726
计量
- 文章访问数: 13
- HTML全文浏览量: 0
- PDF下载量: 11
出版历程
- 收稿日期: 2021-07-17

Calculation and Verification of HVDC Cable on the Current Carrying Capacity

NARI Group Corporation(State Grid Electric Power Research Institute), Nanjing 211106, China

摘要

摘要: 为了掌握高压直流电缆直流载流量，最大限度的利用电缆的输送能力，通过理论计算与试验测量结合的方式，研究了±535 kV高压直流电缆直流载流量。基于IEC 60287计算了导体运行温度为70℃和90℃时的直流载流量，同时搭建了载流量试验回路，实测了运行温度为70℃和90℃时的直流载流量。试验表明，自由空气中敷设、电缆不受日光直接照射，70℃的载流量为3 266 A，90℃的载流量为3 682 A，90℃运行与70℃运行相比载流量提升12.7%；高压直流电缆载流量理论计算结果与实测结果基本一致，两者相差不超过0.5%。
- 高压直流电缆 /
- 载流量 /
- 理论计算 /
- 试验验证
Abstract: In order to master the DC carrying capacity of HVDC cable and make the best use of the transmission capacity of the cable,the DC carrying capacity of±535 kV HVDC cable was studied by combining theoretical calculation with experimental measurement.The DC carrying capacity of conductor laid in free air without direct sunlight was calculated when the operating temperature is 70℃and 90℃based on IEC 60287,at the same time,a test circuit was built to measure the DCload when the operating temperature was 70℃and 90℃.The research shows that the carrying capacity of 70℃is 3 266 A,and that of 90℃is 3 682 A,the carrying capacity of 90℃is 12.7%higher than that of 70℃.The difference between the theoretical calculation results and the measured results is no more than 0.5%,which are basically the same.
- HVDC cable /
- current carrying capacity /
- theoretical calculation /
- experimental verification
